Mining Support Use Water Swelling Friction Anchor Bolt

  • Mining Support Use Water Swelling Friction Anchor Bolt
  • Mining Support Use Water Swelling Friction Anchor Bolt
  • Mining Support Use Water Swelling Friction Anchor Bolt
  • Mining Support Use Water Swelling Friction Anchor Bolt

Mining Support Use Water Swelling Friction Anchor Bolt

    Unit Price: 5~12 USD
    Min. Order: 100 Set/Sets
    Packaging: Packed by plastic bags and wood pallet or as your request
    Productivity: 100,000 sets per month
    Brand: ANTO
    Transportation: Ocean
    Place of Origin: China
    Supply Ability: 100,000 sets per month
    Certificate: SGS
    Port: Qingdao,Tianjin,Dalian

Basic Info

Model No.: ANTO-12

Product Description

20210929111139

Product Description

Water Swelling Friction Bolt is made by high strength welded tube folded itself and welded to seal at both end of bolt.

Working principle:

When the bolt is used in the hole, the bush with a hole is connected with a chuck of a high-pressure water pump. Start the pump and inject the water into tube, the folded wall of bolt is forced to expand. When the pump reaches a standard pressure, the wall of bolt holds onto the strata and creates a big friction strength to support.Thus, a safety and stable support system is formed.


Detail3



Advantages of Water Swelling Friction Bolt:

1. Simple installation, saving labor cost.

2. Be used in wide variety of ground conditons.

3. With high supporting strength.

3


Product Parameters

Item No.

Bolt

Diameter

Steel thickness

Original Tube

Diameter

Bushing

Head

Diameter

Upper Bushing Diameter

Breaking Load

Expansion

Pressure

Minimum Elongation

ATWSF120

28mm

2mm

41mm

30/36mm

28mm

120KN

300bar

20%

ATWSF160

38mm

2mm

54mm

41/48mm

38mm

160KN

240bar

10%

ATWSF240

38mm

3mm

54mm

41/48mm

38mm

240KN

300bar

10%
